FEATURES
- Full GUI with alpha blending
- Individual setting of resolution, frame rates and picture quality
- Instant Replay
- Digital Zoom
- Mouse Control
- Weekly scheduler with holiday by 10 minutes setting
- Covert, Disable and Private function of cameras
- Motion Detection with 576 area setting
- Relay alarm output
- PTZ control by RS-485
- Daylight Saving Time and Network Time Setting
- Multi User Authority
- Deinterlacer upon live and playback
- Multi languages with full graphic
- Individual Network port setting
- Auto Deletion
- Import and Export the configuration
- Interactive setup via network
- POS Interface
- Mirroring
SPECIFICATIONS
| Video | |
|---|---|
| Camera input | 16 BNC |
| Available source | Upto 4K IPC TVI/AHD/CVI 720p25,30/1080p25,30/3MP@18 ~ 30/4MP@12 ~ 30/8MP15 HD-SDI/EX-SDI 720p25,30/1080p25,30/4MP@25,30/8MP15 /Composite/960H/Mixed |
| IP Camera Spec | ONVIF 2.3, RTSP, H.264, H.265 dual stream use gigabit ethnet hub |
| IP Camera Num | 8 |
| IP Camera Restriction | Cannot setup Private ZONE Cannot support Timestamp |
| Output | 2 HDMI (Main Display or Programmable HD Spot) 1 VGA (Main Display or Programmable HD Spot) 1 Composite (Programmable SPOT) |
| Audio | |
| Audio input | 16 RCA |
| Output | 1 RCA |
| Sensor In | 16 (NC, NO selectable) |
| Alarm out | 2 Relay, 14 TTL |
| Operating System | Embedded Linux OS |
| Display | |
| Speed | Real Time |
| Resolution (Pixel) | 1280 × 1024, 1280 × 720, 1920 × 1080, UHD |
| Split screen | 1,4,6,8,9,13,16 |
| Main Recording | |
| CODEC | H.265 |
| Resolution (Pixel), Video IN : Possible Recording |
8MP : 8MP, 720p 4MP : 4MP, 720p 3MP : 3MP, 720p 1080p : 1080p, 720p 720p : 720p, 960 × 540 960H, Composite : 960H, D1 |
| Picture quality | 4 steps (Super, High, Medium, Low) |
| Speed | 480fps @ 1080p |
| Dual Recording | |
| CODEC | H.265 |
| Resolution (Pixel) | 640 × 360 |
| Playback | |
| Display | 1,4,6,8,9,13,16 |
| Speed | 480fps |
| Fast/Slow speed | Normal, REW & FF [recorded speed × 2, × 4, × 8, × 16,x32,x64,x1/2,x1/4], Frame to frame, Pause |
| Network (Individual setting of resolution, frame rates and picture quality) | |
| Network Interface | Gigabit Ethernet |
| High Resolution (Pixel) Video IN : Possible Recording |
8MP : 1080p, 720p 4MP : 1080p, 720p 3MP : 1080p, 720p 1080p : 1080p, 720p 720p : 720p, 960 × 540 960H, Composite : 960H, D1 |
| Low Resolution (Pixel) Video IN : Possible Recording |
8MP : 480 × 256 4MP : 480 × 256 3MP : 480 × 256 1080p : 480 × 256 720p : 480 × 256 960H, Composite : CIF |
| Speed | 140fps @ 1080p |
| Protocol | TCP/IP, HTTP, DHCP |
| Application | Windows 7 / 8 (PC Client system& IE)/MAC |
| Web Browser | Internet Explorer, Safari |
| Smart phone App | Android, iPhone for live and search |
| Backup | |
| Interface | USB 2.0 × 3 |
| Backup device | External HDD and CD/DVD-RW, Network, Thumb Drive |
| The number of HDD | 8 SATA + 1 eSATA(upto 8 bays, No capacity limit ; 8TB or more) |
| Others | |
| Power Consumption | 150W |
| Operating Temperature | 5 ~ 40°C(41 ~ 104F) |
| Relative Humidity | Maximum 80% non-condensing |
| Dimension | 430(W) × 420(D) × 88(H) |
