FEATURES
- Full GUI with alpha blending
- Individual setting of resolution, frame rates and picture quality
- Instant Replay
- Digital Zoom
- Mouse Control
- Weekly scheduler with holiday by 10 minutes setting
- Covert, Disable and Private function of cameras
- Motion Detection with 576 area setting
- Relay alarm output
- PTZ control by RS-485
- Daylight Saving Time and Network Time Setting
- Multi User Authority up to 8 Users
- Deinterlacer upon live and playback
- 22 languages with full graphic
- Individual Network port setting
- Auto Deletion
- Import and Export the configuration
- Interactive setup via network
- POS Interface
- Dual CODEC engine for independent video transmission
- Mirroring
SPECIFICATIONS
| Video | |
| Camera input | 16 POE |
| Technology | ONVIF 2.3, RTSP, dual stream |
| # of IP Camera | 16 |
| Output | 1 HDMI (Main Display) 1 VGA (Main Display) |
| Other I/O | |
| Audio input | 1 RCA |
| Audio Output | 1 RCA |
| Sensor In | 16 (NC, NO selectable) |
| Alarm out | 1 relay |
| Operating System | Embedded Linux OS |
| Display | |
| Speed | Real Time |
| Resolution (Pixel) | 1280 × 1024, 1280 × 720, 1920 × 1080, 3840 × 2160(HDMI only) |
| Split screen | 1,4,6,8,9,13,16 |
| Main IPC | |
| Resolution (Pixel) / fps | main: upto 8MP@ 30 dual: upto 960 × 540 |
| Total Bitrate | 120Mbps |
| Channel Bitrate | 7.5 Mbps |
| Playback | |
| Display | 1,4,6,8,9,13,16 |
| Search mode | Calendar, Event ,POS , Panorama, Thumbnail |
| Fast/Slow speed | Normal, REW & FF [recorded speed × 2, × 4, × 8,×16,×32,×64,×1/2,×1/4], Frame to frame, Pause |
| Other | |
| Backup device | External HDD, CD&DVD-RW, Network, Thumb Drive |
| Network Interface | Gigabit Ethernet |
| The number of HDD | 2 SATA + 1 eSATA (upto 12 bays, No capacity limit ; 6TB or more) |
| Power Consumption | 190W (SMPS) |
| Operating Temperature | 5 ~ 40ºC(41 ~ 104ºF) |
| Relative Humidity | Maximum 80% non-condensing |
| Dimension | 380(W) × 340(D) × 50(H) mm |
