FEATURES
- 8.29 MP (4K) High Performance CMOS
- Auto Focus
- 3840 × 2160 Resolution
- 2.7 ~ 13.5 mm Motorized Vari-focal Lens
- EXIR 2.0, Smart IR, up to 197ft (60m) IR distance
- OSD menu, DNR
- 4 in 1 video output (switchable TVI / AHD / CVI / CVBS)
- IP67
- Up the coax (UTC)
SPECIFICATIONS
| Camera | |
|---|---|
| Image Sensor | 8.29 megapixel progressive scan CMOS |
| Signal System | PAL/NTSC |
| Frame Rate | TVI: 8MP@12.5fps, 8MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, 2MP@30fps CVI: 8MP@12.5fps, 8MP@15fps AHD: 8M@12.5fps, 8M@15fps CVBS: 960H P/N |
| Resolution | 3840 (H) × 2160 (V) |
| Min. Illumination | Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Speed | PAL: 1/12.5s to 1/50,000s NTSC: 1/15 s to 1/50,000s |
| Lens | 2.7 mm to 13.5 mm motorized vari-focal lens |
| Horizontal Field of View | 108.1° to 45.6° |
| Lens Mount | Φ 14 |
| Day/Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 355°; tilt: 0° to 75°; rotate: 0° to 355° |
| Synchronization | Internal synchronization |
| DWDR (Digital Wide Dynamic Range) | 105 dB |
| Menu | |
| AGC | Supported |
| Day / Night Mode | Auto / Color / BW (black and white) |
| White Balance | Auto/Manual |
| BLC | Yes |
| DWDR | Yes |
| Language | English |
| Functions | Brightness, sharpness, DNR, mirror, Smart IR, HLC |
| Interface | |
| Video Output | 1 HD analog output |
| Switch Button | TVI / AHD / CVI / CVBS |
| General | |
| Operating Conditions | -40° F to 140° F (-40° C to 60° C), humidity: 90% or less (non-condensation) |
| Power Supply | 9 VDC to 15 VDC |
| Power Consumption | Max. 6.4 W |
| Protection Level | IP67, IK10 |
| Material | Metal |
| IR Range | Up to 197ft (60m) |
| Communication | Up-the-Coax |
| Dimensions | Ø 5.69″ × 4.37″ (Ø 145 mm × 111.3 mm) |
| Weight | Approximately 1.90lb. (860g) |
